ELECTRONIC VARIABLE SPEED 14"x20" WOOD LATHE 750W
Main features:
* The lathe is constructed from cast iron and includes a powerful 750W universal DC motor with electronic speed control that provides full torque at all speeds.
* Three belt ratios for a high torque when turning large diameters
* Digital speed display on the bed
* All cast iron construction for high stability and vibration-free running
* 24 Indexing Positions Function
* With Forward and Reverse running function
Specifications:
01) Description: 14"x20" Variable Speed Lathe
02) Motor: 750W
03) No. of Speed: Variable
04) Spindle Speed: 250~3550 rpm
05) Swing Over Bed: 355mm (14")
06) Distance Between Centers: 510mm (20")
07) Drive Spindle thread: M33X3.5 or others
08) Headstock and Tailstock Taper: MT2#
09) Face Plate: 102mm (4")
10) Tool Rest: 204mm (8")
11) Packing Size: 980X300X565 mm
12) Net/Gross weight: 50/53.5 kgs
* Optional Extension bed 610mm (24 inches)
